CNC Controller
|
Fanuc/Siemens/Mitsubishi |
|
Max Swing Over Bed (mm)
|
115 |
|
Chuck Size (mm)
|
135 |
|
Standard Turning Diameter (mm)
|
65 |
|
Max Turning Length (mm)
|
75 |
|
Job Clamping System
|
Chuck |
|
Type Of Guide Ways
|
LM Guides with Balls |
|
X Axis Travel (mm)
|
140 |
|
Z Axis Travel (mm)
|
140 |
|
Rapid Feed Rate ( X and Z) (Meters/Min)
|
22 |
|
Spindle Motor Power (KW)
|
3.7/5.5 |
|
Spindle Bore (mm)
|
38 |
|
Spindle Nose
|
A2-4 |
|
Max Bar Capacity (mm)
|
25 |
|
Spindle Speed Range (rpm)
|
4500 |
|
No. Of Tools
|
4 |
|
Tooling Arrangement Type
|
Linear |
|
Tool Shank Size
|
20 x 20 |
|
Max Boring Bar Capacity (mm)
|
25 |
|
Positioning Uncertainty (mm)
|
0.010 |
|
Repeatability (mm)
|
0.005 |
|
Machine Weight (Approx) (kg)
|
1300 |
