Picture of Cnc Vtl 300

Cnc Vtl 300

Be the first to review this product

Call for pricing

Qty:

Specifications
Reviews
Contact Us

Products specifications

CNC Controller	Fanuc/Siemens/Mitsubishi
Max Turning Dia (mm)	440
Max Turning Length (mm)	450
Max Swing Over Bed (mm)	640
Standard Turning Diameter (mm)	300
X Axis Travel (mm)	235
Z Axis Travel (mm)	425
Rapid Feed Rate ( X and Z) (Meters/Min)	20
Spindle Nose	A2-6
Spindle Motor Power (KW)	11/15
No. Of Tools	8
Max Boring Bar Capacity (mm)	40
Tool Shank Size	25 x 25
Positioning Uncertainty (mm)	0.010
Repeatability (mm)	0.005
Machine Weight (Approx) (kg)	6000
