CNC Controller
|
Fanuc/Siemens/Mitsubishi |
|
X Axis Travel (mm)
|
570 |
|
Y Axis Travel (mm)
|
570 |
|
Z Axis Travel (mm)
|
570 |
|
Distance From Pallet Surface To Spindle Center (mm)
|
100-670 |
|
Distance From Pallet Center To Spindle Nose (mm)
|
150-715 |
|
Pallet Size (mm)
|
400x400 |
|
Max Weight On Pallet (kg)
|
400 |
|
Min Pallet Indexing (degree)
|
1 |
|
Pallet Indexing Time (sec)
|
8 |
|
Rapid Feed Rate ( X Y Z) (Meters/Min)
|
24 |
|
Spindle Taper
|
BT 50 |
|
Spindle Speed Range (rpm)
|
6000 |
|
Spindle Motor Power (KW)
|
7.5/11 |
|
ATC - No Of Tools
|
24 |
|
Max Tool Weight (kg)
|
20 |
|
Max Tool Length (mm)
|
400 |
|
Tool Changing Time (sec)
|
3.5 |
|
Positioning Uncertainty (mm)
|
0.010 |
|
Repeatability (mm)
|
0.007 |
|
Machine Weight (Approx) (kg)
|
14000 |
